Controllers Temperature Controllers Standard Type TC4S-14R
Product Paramenters
SizeDIN W48×H48mmDisplay method4-digit 7-segment LEDControl methodON/OFF, P, PI, PD, PIDInput specificationThermocouple: K(CA), J(IC), L(IC)RTD: DPt100Ω, Cu50ΩSampling cycle100msControl outputRelay (250VAC~ 3A) or SSR...
- Overview
- Related Products
Product Paramenters
Size |
DIN W48×H48mm |
Display method |
4-digit 7-segment LED |
Control method |
ON/OFF, P, PI, PD, PID |
Input specification |
Thermocouple: K(CA), J(IC), L(IC) RTD: DPt100Ω, Cu50Ω |
Sampling cycle |
100ms |
Control output |
Relay (250VAC~ 3A) or SSR drive (12VDC ) [ON/OFF, phase, cycle] |
Option output |
Alarm 1 |
Power supply |
100-240VAC~ 50/60Hz |
Weight |
Approx. 141g(approx. 94g) |
TC4S-14R
* Size : DIN W48×H48mm
* Display method : 4-digit 7-segment LED
* Control method : ON/OFF, P, PI, PD, PID
* Input specification : Thermocouple: K(CA), J(IC), L(IC)
RTD: DPt100Ω, Cu50Ω
* Sampling cycle : 100ms
* Control output : Relay (250VAC~ 3A) or SSR drive (12VDC ) [ON/OFF, phase, cycle]
* Power supply : 100-240VAC~ 50/60Hz
* Display method : 4-digit 7-segment LED
* Control method : ON/OFF, P, PI, PD, PID
* Input specification : Thermocouple: K(CA), J(IC), L(IC)
RTD: DPt100Ω, Cu50Ω
* Sampling cycle : 100ms
* Control output : Relay (250VAC~ 3A) or SSR drive (12VDC ) [ON/OFF, phase, cycle]
* Power supply : 100-240VAC~ 50/60Hz
