H7CC-AD 12-48VDC/24VAC Preset Counter Digital Counter H7CC-AD
Product Paramenters
ClassificationConfigurationExternalconnectionsSettingsDisplaydigitsOutputsPowersupplyvoltageModelPreset counter• 1-stagepreset counter• Total andpreset counter8-pin socket1-stage6 digitsContact output(SPST)100 to240 V...
- Overview
- Related Products
Product Paramenters
Classification |
Configuration |
External connections |
Settings |
Display digits |
Outputs |
Power supply voltage |
Model |
Preset counter |
• 1-stage preset counter • Total and preset counter |
8-pin socket |
1-stage |
6 digits |
Contact output (SPST) |
100 to 240 VAC |
H7CC-A8 |
24 VAC/ 12 to 48 VDC |
H7CC-A8D |
||||||
11-pin socket |
Contact output (SPDT) |
100 to 240 VAC |
H7CC-A11 |
||||
Transistor output (SPST) |
H7CC-A11S |
||||||
Contact output (SPDT) |
24 VAC/ 12 to 48 VDC |
H7CC-A11D |
|||||
Transistor output (SPST) |
H7CC-A11SD |
||||||
Screw terminals |
2-stage |
Contact output (SPDT) |
100 to 240 VAC |
H7CC-A |
|||
Transistor output (SPST) |
H7CC-AS |
||||||
Contact output (SPDT) |
24 VAC/ 12 to 48 VDC |
H7CC-AD |
|||||
Transistor output (SPST) |
H7CC-ASD |
||||||
Preset counter/ Tachometer |
• 1-stage preset counter • 2-stage preset counter • Total and preset counter • Batch counter • Dual counter • Twin counter • Tachometer |
Contact output (SPST+SPDT) |
100 to 240 VAC |
H7CC-AW |
|||
Transistor output (DSPT) |
H7CC-AWS |
||||||
Contact output (SPST+SPDT) |
24 VAC/ 12 to 48 VDC |
H7CC-AWD |
|||||
Transistor output (DSPT) |
H7CC-AWSD |
||||||
Contact output (SPDT) + Transistor output (SPST) |
100 to 240 VAC |
H7CC-AU |
|||||
24 VAC/ 12 to 48 VDC |
H7CC-AUD |
